KN-127 Petroleum Wax Melting Point Tester

Overview

  KN-127 Petroleum Wax Melting Point Tester conforms to ASTM D127 Standard Test Method for Drop Melting Point of Petroleum Wax, Including Petrolatum. Melting point is a wax property that is of interest to most wax consumers. It can be an indication of the performance properties of the wax. Drop melting point, Test Method D127, is often used to measure the melting characteristics of petrolatum and other high viscosity petroleum waxes.

 Features

1.Digital display PID temperature controller, with accuracy of ±1℃

2.The instrument adopts temperature-resistant high borosilicate glass cylinder, which can observe the sample transparently and has good heat preservation performance.

3.The instrument adopts the compressor refrigeration, which produces a large amount of refrigeration to maintain the temperature constant

4.This instrument is formed by steel plate, and the surface adopts electrostatic spraying process, which is durable and strong in corrosion resistance.

Technical parameters

1.Applicable standard：ASTM D127 ISO2707

2.Wax bath temperature range: 4℃±0.1℃

3.Transparent bath temperature range: 16~150℃ (ambient temperature ≤20℃)

4.Temperature control mode: Digital display temperature programming

5.Heating mode: SS electric tube heating

6.Cooling mode: Compressor

7.Test stations: 2

8.Heating power: 1500W

9.Cooling power: 500W

10.Total power: 2000W

11.Rated voltage : AC220V±10%, 50Hz
