KN-7279C Automated Houillon Viscometer

Overview

    KN-7929C Automated Houillon Viscometer conforms to ASTM D7279 Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids by Automated Houillon Viscometer. Many petroleum products and some non-petroleum products are used as lubricants in the equipment, and the correct operation of the equipment depends upon the appropriate viscosity of the lubricant being used. Additionally, the viscosity of many petroleum fuels is important for the estimation of optimum storage, handling, and operational conditions. Thus, the accurate determination of viscosity is essential to many product specifications.

Features

1. Single-chip microcomputer control, color touch screen operation, stable and reliable

2. Fast test speed, some results can be got within 30s, generally will get results around 3~5 minutes

3. Measurement, cleaning, drying and result calculation will be done automatically

4. Fast cleaning speed with low cost, every cleaning will cost only about 10ml cleaning solvent

5. Software and hardware double over-temperature protection, over-temperature alarm, anti-dry burning protection function.

6. Required sample volume is less than 1ml

7. Be able to calculate the viscosity index, and with multi-point temperature correction function

Technical parameters

1. Viscosity measuring range: 0.5~3000 (select the corresponding viscometer by the required range)

2. Temperature control range: 20~100℃ (External cooling source is required for 20℃)

3. Temperature accuracy: ±0.02℃

4. Test station: Two

5. Timing accuracy: 0.01s

6. Test accuracy≤0.68%

7. Heating mode: Spiral heater

8. Display: Color touch screen

9. Control mode: Automatic measurement, cleaning and drying

10. Data storage: 1000 pieces

11. Rated voltage: AC220V±10%, 50Hz

12. Total power: 1500W

13. Dimension: 160*400*350mm

14. Weight: 15kg
